How to Connect RangeXTD Booster to Nighthawk AX5400?

The RangeXTD Booster is a WiFi booster. It offers a super-fast and seamless internet connection in every home location. If you are seeking the most effective instructions for setting up a Range XTD booster, our guide will enhance your home’s connectivity. This article contains all the information you require, from the unboxing of your booster to the establishment of a seamless connection in every room of your residence. Follow the given steps to connect your RangeXTD booster to Nighthawk AX5400 router. Let’s start:

Setup Range XTD booster

To RangeXTD setup, first install the booster by follow the given below steps. After that there are three methods to configure the booster:

1. Manual Setup
2. Setup via the Range XTD app
3. WPS button

Physical Setup of Booster

1. Simply plug in the Range XTD booster near to the router.
2. Shut down the router and the modem, and then attach the booster to the router.
3. After that, turn on the booster and also turn on the all network devices.

After physically install the booster, configure the booster with any one of the above method.

Manual Setup

In manual setup, you configure the booster to the router with the help of RangeXTD login process. Access the web interface of the booster. Steps how you can do it;

1. Use the LAN cable to connect the computer to the booster and use network name to connect wirelessly.
2. Open the web browser, go to the address bar and type 192.168.7.234
3. Enter the RangeXTD login details that given on the back side of the booster.
4. Click on the login button and you are directly on the web interface of the booster.
5. On interface, Select and enter the password of the network name which you want to extend.

After that, move the booster at that place where the signals are weak and slow. Do not place the booster out of the router range. On this interface, set the password for booster.

Setup via the Range XTD App

Setup via Range XTD app is the easiest way to configure the booster to the router. Here you need to download the Range XTDApp from the play store or the app store. Follow the steps for further process.

1. Firstly, connect the mobile to the network of the booster.
2. After download the app, open the app by tap on it.
3. Enter the login details to login.
4. (Username and password are mentioned on the label or the user manual of the booster )
5. Click on the next button, and enter the serial number of the booster.
6. Then select the network name of the router and enter the password, click on APPLY button.

Now your booster is able to extend the network at every corner of your home. If you don’t want to use the manual or via the app both method, then you can use the WPS method to use.

WPS Button

WPS method is the easiest way to setup the booster. When you are use the WPS method then you do not need to configure the booster to the router, because in this booster inherit all the settings and password of the router. Steps to perform WPS method:

1. Simply press the WPS button of the Nighthawk AX5400 router and within two minutes push the button of the RangeXTD booster.
2. Now it takes little amount of time to connect booster to the router.

When you are using WPS method, then you can use same password of the router to connect the devices to the network.

Conclusion

In the post that you just read, you will find detailed instructions on how to perform the Range XTD Setup with Nighthawk AX5400 using all of the available methods, including the manual approach, the app method, and the WPS technique.

FAQs

What if my RangeXTD is not showing up in the Wi-Fi list?

If you don’t see the RangeXTD network when searching for available Wi-Fi networks, try the following:

1. Ensure it’s plugged in correctly and the light is on.
2. Turn off your phone or computer’s Wi-Fi, wait a few seconds, and then turn it back on.
3. 3. If still no connection, reset the RangeXTD and try again.

Can I connect my RangeXTD to more than one router?

No, the RangeXTD can only connect to one router at a time. However, if you have multiple RangeXTD boosters, you can set them up to cover different areas of your house.

How far can I place the RangeXTD from the Nighthawk AX5400 router?

Place the RangeXTD about halfway between your router and the area with weak Wi-Fi. If it’s too far from the router, it won’t pick up the signal well. If it’s too close, it won’t extend the signal far enough. Aim for a balance.
